GeoFactory Explo 14" Core Saw
This item is quoted upon request. To receive pricing please add it to your cart, then click the "add to quote" button on the cart page.
Country Of Origin: Spain
This model of slabbing saw, with a diamond blade, is ideal for the mining industry. It ensures precise cutting of geological samples and is easy to move during mining drilling operations. Now built in stainless steel, it offers enhanced durability and corrosion resistance for demanding environments.
The Explo Core Saw is an exclusive design, engineered to slab drill core sections up to 50 cm in length and PQ (3.35" / 85mm) in diameter. This versatile tool is portable and ideal for both on-site applications and core logging facilities. It features a powerful tri-phase 5.5 HP motor as standard and includes an efficient recirculating water system for optimal operation.
|
Material |
Stainless steel with aluminium profiles and polycarbonate |
|
Dimensions: |
1370 x 780 x 1470 mm / 53.9 x 30.7 x 57.9 inch |
|
Weight: |
132 kg / 291 lbs
|
| Motor | |
|
Power supply: |
380-400 VaC, 50 / 60 Hz – Three-phases
|
|
Motor power: |
5.5 HP |
|
RPM: |
2750 |
|
Core support |
|
|
Maximum cutting depth: |
From AQ (1.06" / 27mm) to PQ (3.35" / 85mm) with 14” blade |
|
Maximum cutting length: |
500 mm |
|
Diamond blade |
|
|
Diameter: |
350 mm/ 14 in |
|
Fluid system |
|
|
Pump: |
Water pump: 1.1 kW / 50 L / min |
|
Lubricant system: |
3x Nozzles |
|
Tank capacity: |
Standard: 100 L Decanting tank: 300 L (Optional) |
